DETAILS
Quick facts about the iTECH240X PRO:
The all-new iTECH240X PRO 240Ah Lithium Battery is the result of years of design and development. Featuring a 100% useable capacity, the iTECH240X PRO is the ultimate power solution for all your energy needs.
With its sleek and compact design, the iTECH240X PRO is a true drop-in replacement for your existing system. No changing of systems, chargers, or equipment is required in most cases. Simply pull out your old AGM or lead-acid batteries and drop in the iTECH240X PRO. It's that easy!
The iTECH240X PRO features a fully 100% useable capacity, allowing the full 240Ah to be drawn from the battery. The new iTECH240X PRO includes an all-new patent-pending prismatic cell type, as well as an all-new supercharged Battery Management System (BMS) allowing for less cell degradation and a longer lifespan with high current use.
Built for the tough Australian environment, the iTECH240X PRO is IP67 Waterproof rated, allowing for the battery to be submerged under 1 meter of water for up to 30 minutes - perfect for marine applications or outdoor storage boxes. The iTECH240X PRO utilizes the latest prismatic cell design offering more vibration resistance and stability for big bumps with vibration-dampening technology.
Upgrade to the iTECH240X PRO today and experience the ultimate in power and performance.
Package contents of the iTECH240X PRO
- 1x iTECH240X PRO 240Ah 12V Lithium Battery
- 1x Instruction Manual (Digital version )
Support
The iTECH240X PRO warranty is 5 years (3 years full replacement 2 years pro-rata).
*Storage deep cycle battery only. It cannot be used as a cranking battery.
If your iTechworld battery enters safe mode, please follow the instructions
SPECIFICATIONS
SPECIFICATIONS
| Nominal Voltage: | 12.8V |
| C20 Rating usable amps 10v: | 240Ah |
| Short Circuit Protection: | Yes |
| Optimum Temperature Range: | 5 to 60°C |
| BMS Operational Temperature Range: | -5 to 80°C |
| Safety Protection Isolator: | 80°C |
| Recommended Charge Current: | 1 - 100A |
| Maximum Charge Current: | 200A |
| Recommended Charge Voltage: | 14.4V |
| BMS Charge Cut Off Voltage: | 15V |
| BMS Low Voltage Cut Off: | 8.5 - 9V |
| Continuous Discharge: | 250A |
| Peak Discharge: | 500A (5 secs) |
| Series Connection: | Up to 48V (4 x batteries) |
| Parallel Connection: | |
| Life Cycles 100%: | 4000 |
| Life Cycles 50%: | 8000 |
| Dimensions (LxWxH): | 485x170x239mm (245mm including terminals) |
| Weight: | 23.6Kg |
| Terminal Type: | M8 |
| Case Material: | ABS |
| Safety Certifications: | |
| UL Certified 1642 | |
| CE Certified | |
| IP67 Rated | |
| Rohs Certified | |
| UN38.3 Certified | |
| ISO 9001 Certified | |
| ISO 1400 Certified | |
| IEC:62619 Certified |
